The Steele 90 Series is our second-largest stiff extruder and pug sealer combination, producing up to 81 metric tons per hour of green products. The durability of these green products permits direct setting on kiln cars or transfer across multiple belts before curing or firing.

• Suitable for fine plastic clays, rocky non-plastic shales, abrasive fines and dusts
• High-quality production with less processing than soft extrusion systems
• Multiple drive options
• Uses a wide range of dies
• Minimal maintenance and downtime

Eliminate the cost of adding and removing water

The 90 Series processes materials between 5-20% moisture and varying degrees of plasticity, to handle a wider range of raw materials than comparable machines. The 90AD Extruder produces solid pavers and bricks, block and tile with void areas up to 65%, and robust pellets and aggregates with superior strength and structural integrity right out of the die.

Our global installed base includes 90 Series machines running for over forty years, backed by Steele service and parts.

The Steele 90BD Pug Sealer ensures superior pugging at the highest capacities
